What Are Keys Specs & Differences Between GN500 And GNW500

Infinity Trailers is a leading car trailer manufacturer in Texas that specializes in designing and manufacturing a wide range of auto transport trailers. The company offers 2 high capacity belly deck 5 car trailers known as GN500 and GNW500. In this blog, we are going to discuss key specifications and major differences between these two models.
GN500: GN500 is one of the popular auto transport trailers offered by the Infinity Trailers in Texas. This trailer comes with 34' top loading capacity.
Key specifications of GN500:
- Top Loading Capacity: 34'
- Bottom Loading Capacity: 42'
- Overall Length: 50'
- Bed width: 102"
- 25,000lb. GVWR
- Hydraulic Ramps
- Trailer Weight: 13,000Lb.
- Tandem Duals with Hydraulic Brakes
- Roadmaster tires and wheels
- Spare Tire and Holder
- Single Acting Hydraulic Pump (12 volt self contained unit)
- 12 volt battery
- 2" King Pin 3/8" Bolster
- 1 breakaway kit
- Reflector Tape
- LED Lighting
- Punch Hole decking for Treadways and ramps
- 2 - 14"x16"x24" Tool Boxes
- Aluminum Cylinders for upper deck: 2- 2.5"x48"
- Cylinders for Hydraulic Ramps: 1 - 2"x96"
- Bulldog 10K Side Wind Dropleg Jack
- Wheel Strap with Swivel Hooks and Rubber Blocks
- 7 Way Flat Pin RV Plug
- Dual Pole Plug - Trailer Side with 4 Guage Charge Wire
GNW500: GNW500 is the tripod version of GN500. It is a 50 ft 5 car hauler that has a belly deck. This trailer also comes with hydraulic ramps & tandem duals. It gives 34' top loading capacity. The GNW500 auto transport trailer is the advanced model of GN500.
Key specifications of GNW500:
- Top Loading Capacity: 34'
- Bottom Loading Capacity: 42'
- Overall Length: 50'
- Bed width: 102"
- 25,000lb. GVWR
- Hydraulic Ramps
- Trailer Weight: 13,000Lb.
- Tandem Duals with Hydraulic Brakes
- Roadmaster tires and wheels
- Spare Tire &Holder
- Single Acting Hydraulic Pump (12 volt self contained unit)
- 12 volt battery
- 2" King Pin 3/8" Bolster
- 4 1/2" Square 8" Adjustable Coupler 25K
- 1 breakaway kit
- Reflector Tape
- LED Lighting
- Punch Hole decking for Treadways and ramps
- Tool Boxes: 1 - 18"x18"24"
- Aluminum Cylinders for upper deck: 2- 2.5"x48"
- Cylinders for Hydraulic Ramps: 1 - 2"x96"
- Bulldog 10K Side Wind Dropleg Jack
- 20 Over the Wheel Strap with Swivel Hooks and Rubber Blocks
- 7 Way Flat Pin RV Plug
There are no huge differences between GN500 & GNW500. Both come with the same features. If you are looking for a tripod 5 car trailer then GNW500 is good for you. Otherwise you can go with GN500.
